Model: RPD210
• Data can be display on 20 columns x 2 lines
• Display panel is adjustable to provide the best view angle
• Provide 2 pole for best position installation
• Esc/pos command compatible
• International character set is selectable
• User-defined characters can be download
• User-defined message can be download
• Green power function. USB Powered.
Customer Display RPD 210
Description
| Model | RPD-210 |
| Display | |
| Display Method | Vacuum Fluorescent Display (blue green) |
| Brightness | 700 cd/m2 |
| Number of character | 40 characters (20 columns x 2 lines) |
| Viewing | |
| Character font | 5 x 7 dot matrix |
| Character size | 3.50mm x 5.00 mm |
| Character Type | 96 alphanumeric, 13 international character sets, 1 user define character, 14 code page |
| Electrical | |
| Power Supply | Powered by USB, +5Vdc and +9 ~ 35Vdc are optional |
| Power Consumption | 2W (Max.) |
| MTBF | 30,000 hours (power on time) |
| Operations | |
| Operating Temperature | 0 ~ 45 |
| Operating Humidity | 10 ~ 90 % RH |
| Storage Temperature | -10 ~ 50 |
| Storage Humidity | 10 ~ 90 % RH |
| Module Dimensions | 146 (W) x 49.2 (H) x 26.4 (D) mm |
| Display Dimensions | 176(W) x 130(D) 355(H)mm, 176(W) x 130(D) 224(H)mm, 176(W) x 130(D) 135(H)mm |
| Connectivity | Data & Power – USB |
| Module Weight | 172 g |
| Display Weight | 0.5 kg |
